CNC 5 axis Processing Center Router Machine

收藏
Trade description

The Recoji (Our own designed machines )Series 5 Axis CNC Processing Center Router Machine is a profesional stable good quality multi axis cnc 5 axis router, it is ready for production cutting, drilling, trimming, as well as prototype-and fixture-machining in a large work envelope, accessible from all angles. High class 5 aixs is a very high price machine, but now you will have a good price for this kind of machines, we are sure this can help you create more.



Because of the high price for 5 axis system, we choose wordwide good brand system for this machine, 5 axis moving Axis. Supply the post, customers will be easy to update, we have suitable high price version, but if customers can do all by yourself, this is a good machine to run.



Series

RECOJI2500

Travelling Size

2860*3560*1000mm

Working Size

2500*3000*850mm

Table size

3250*5250mm

Transmission

X/Y rack and pinion drive,Z ball screw drive, A and B   axis with robot gears

A and B axis moving range

A and B: -120 degree to +120 degress

Motion Parts

All axes with linear guides

Table structure

Aluninum T slot table

Spindle Power

3.7;5.5;9KW (Option: customized by customers) Italy   INTEGRATED 5axis head

Spindle speed

24000 r/min

Travelling Speed

60m/min

Working speed

35m/min

Tool

ER

Driving system

Japanese AC servo

Voltage

AC380V/3PH/50HZ (Option: customized by customers)

Controller

Syntec 5axis system with RTCP
